EU Standard EV Charger Model 3 Straight Cable 16A 250V
EU Standard EV Charger Model 3 Straight Cable 16A 250V
Couldn't load pickup availability
Support for color customization. Contact us for more product's informations.
*Mechanical property:
Cable Specification: 3*2.5mm²+2*0.5mm²
mechanical life: No-load plug in/out >10000 times
Impact external force:
Ability to withstand 1M height drop and the rolling of a 2T-vehicle.
*Electrical property:
Voltage input rating: 250V/480V
AC power input rating: 16A/20A/32A
Insulation Resistance: >1000M Ω (DC500V)
Terminal Temperature Rise: <50K
Withstand Voltage: 2500V
Contact Impedance: 0.5m Ω Max
*C-CPD application:
Over voltage protection
Under voltage protection
Overload protection
Short circuit protection
Earth leakage protection
Over temp protection
Surge protection
RCD
CP exception protection
![EU Standard EV Charger Model 3 Straight Cable 16A 250V](http://vschnel.com/cdn/shop/files/3.jpg?v=1684206075&width=1445)
![EU Standard EV Charger Model 3 Straight Cable 16A 250V](http://vschnel.com/cdn/shop/files/10.jpg?v=1684206075&width=1445)
![EU Standard EV Charger Model 3 Straight Cable 16A 250V](http://vschnel.com/cdn/shop/files/2_88da1cb9-1432-4974-8e86-c25afc7f0ce4.jpg?v=1685931113&width=1445)
![EU Standard EV Charger Model 3 Straight Cable 16A 250V](http://vschnel.com/cdn/shop/files/6.jpg?v=1685931113&width=1445)
![EU Standard EV Charger Model 3 Straight Cable 16A 250V](http://vschnel.com/cdn/shop/files/1_083bfde2-b431-44d3-91e6-db70e4f050f8.jpg?v=1685931113&width=1445)
