Support for color customization. Contact us for more product's informations.
*Mechanical property:
Cable Specification: 5*2.5mm²+2*0.5mm²
mechanical life: No-load plug in/out ＞10000 times
Impact external force:
Ability to withstand 1M height drop and the rolling of a 2T-vehicle.
*Electrical property:
Voltage input rating: 250V/480V
AC power input rating: 16A/20A/32A
Insulation Resistance: ＞1000M Ω (DC500V)
Terminal Temperature Rise: ＜50K
Withstand Voltage: 2500V
Contact Impedance: 0.5m Ω Max
*C-CPD application:
Over voltage protection
Under voltage protection
Overload protection
Short circuit protection
Earth leakage protection
Over temp protection
Surge protection
RCD
CP exception protection
